Product Advantage:
1. High Efficiency: Our machine ensures fast and efficient filling and sealing of plastic tubes, increasing productivity and reducing production time.
2. Versatile Application: From creams to lotions, our machine is suitable for filling a wide range of paste products, providing versatility for various industries.
3. Precise Filling: With its advanced technology, our machine delivers accurate and consistent filling, ensuring uniform product quantity in each tube.
4. Leak-proof Sealing: The machine guarantees a reliable and leak-proof seal, preserving product freshness and preventing any potential leakage during storage or transportation.
5. Easy Operation: Our machine is user-friendly and easy to operate, with intuitive controls and minimal training required, allowing for seamless integration into production lines.
Technical Parameters:
Model | WJ—400L | WJ—400F |
Material of hose | Metal tube, aluminum tube | Plastic pipe, composite pipe |
Hose diameter | φ10—φ50 | φ15—φ60 |
Hose length | 60—250（customizable） | 60—250（customizable） |
Filling volume | 5—400ml/piece（adjustable） | 5—400ml/piece（adjustable） |
Accuracy | ≤±1% | ≤±1% |
Production capacity (pcs/minute) | 30—50（adjustable） | 30—50（adjustable） |
Working pressure | 0.55—0.65mpa | 0.55—0.65mpa |
Motor Power | 2kw(380V/220V 50Hz) | 2kw(380V/220V 50Hz) |
Heat sealing power | 3kw | 3kw |
External dimensions | 2620*1020*1980mm | 2620*1020*1980mm |
Weight | 1100kg | 1100kg |
Product Operate Guide:
1. Tube Preparation: Ensure the plastic tubes are clean and properly aligned before loading them onto the machine.
2. Adjust Settings: Set the machine parameters according to the specific product requirements, including filling volume, sealing temperature, and sealing time.
3. Load Product: Fill the product into the tubes using the designated filling mechanism, ensuring accurate and consistent filling.
4. Activate Machine: Start the machine and monitor the filling and sealing process, ensuring proper sealing and smooth operation.
5. Maintenance and Cleaning: Regularly clean and inspect the machine, following the provided maintenance guide to ensure optimal performance and longevity.
FAQ:
1. Can the machine handle different tube sizes and shapes?
Yes, our machine is designed to accommodate various tube sizes and shapes, providing flexibility for different packaging requirements.
2. Is it possible to adjust the filling volume?
Absolutely, our machine allows for precise adjustment of the filling volume, ensuring accurate and consistent product quantities in each tube.
3. What types of materials can the machine work with?
Our machine is compatible with a wide range of plastic materials, including PE, PP, and laminated tubes, making it suitable for various industries.
4. How can I ensure the sealing quality of the tubes?
Our machine is equipped with advanced sealing technology, combined with adjustable sealing parameters, to ensure a reliable and leak-proof seal.
5. Is technical support available after purchase?
Yes, we provide comprehensive technical support, including installation guidance, troubleshooting assistance, and maintenance advice to ensure smooth operation of the machine.
