Product Advantage:
1. Versatile Mixing Capability: Our agitator is designed to handle a wide range of products, including liquids, pastes, and creams, making it suitable for various industries.
2. Efficient and Powerful: With its high-powered motor and efficient gearbox, this mixer agitator ensures thorough and consistent mixing, resulting in superior product quality.
3. Durable and Reliable: Built with high-quality materials and robust construction, this agitator is designed to withstand demanding industrial environments and provide long-lasting performance.
4. Easy to Install and Operate: Our mixer agitator is user-friendly, with simple installation and intuitive controls, allowing for hassle-free operation and increased productivity.
5. Customizable Options: We offer customization options for tank size, agitator speed, and other specifications, tailoring the agitator to meet your specific industry requirements.
Technical Parameters:
Technical Parameters | Specifications |
Spiral stirring paddle power | 1.5kw |
Spiral stirring paddle speed | 0-63r/min |
Homogenizer power | 4kw |
Homogenizer speed | 6000r/min |
Pressure | 0.08Mpa |
Motor Power | 5 kW |
Control System | PLC touch screen |
Material | Stainless steel 304 |
Sealing Method | Mechanical seal |
Safety Features | Overload protection, emergency stop button |
Dimensions (L x W x H) | 1200mm x 800mm x 1600mm(can be customized) |
Weight | 500 kg |
Model | Capacity(L) | Mixing | Homogenizing |
|
| Power（kw） | Speed(r/min） | Power（kw） | Speed(r/min） |
WJ-DM50 | 50 | 0.55 | 0-60 | 1.5 | 0-3000 |
WJ-DM100 | 100 | 0.75 | 0-60 | 1.5 | 0-3000 |
WJ-DM200 | 200 | 1.5 | 0-60 | 3 | 0-3000 |
WJ-DM300 | 300 | 2.2 | 0-60 | 4 | 0-3000 |
WJ-DM500 | 500 | 2.2 | 0-60 | 5.5 | 0-3000 |
WJ-DM1000 | 1000 | 4 | 0-60 | 11 | 0-3000 |
WJ-DM2000 | 2000 | 5.5 | 0-60 | 15 | 0-3000 |
WJ-DM3000 | 3000 | 7.5 | 0-50 | 18.5 | 0-3000 |
WJ-DM5000 | 5000 | 11 | 0-50 | 22 | 0-3000 |
Product Uses:
1. Paint and Coatings Industry: The agitator efficiently blends and homogenizes paint and coating formulations, ensuring a consistent and smooth finish.
2. Cosmetics and Personal Care Industry: It is ideal for mixing and emulsifying creams, lotions, and other cosmetic products, ensuring a uniform and luxurious texture.
3. Food and Beverage Industry: The agitator is used for blending and mixing various food products, such as sauces, dressings, and fillings, ensuring a consistent taste and texture.
4. Chemical Industry: It is suitable for mixing and agitating chemical formulations, including adhesives, resins, and polymers, ensuring proper dispersion and uniformity.
5. Pharmaceutical Industry: The agitator is utilized for blending and mixing pharmaceutical creams, ointments, and gels, ensuring precise and consistent formulations.
Product Operate Guide:
1. Ensure the agitator is securely installed and all connections are properly made before starting operation.
2. Adjust the agitator speed and intensity according to the viscosity and characteristics of the product being mixed.
3. Gradually add the liquid, paste, or cream into the mixing tank while the agitator is running for effective blending.
4. Regularly monitor the mixing process to ensure uniformity and make any necessary adjustments as needed.
5. After each use, thoroughly clean the agitator to prevent cross-contamination and maintain optimal performance.
FAQ:
1. Can the agitator handle high-viscosity materials such as thick creams or pastes?
Yes, our agitator is designed to efficiently mix and blend high-viscosity materials, ensuring a consistent and homogeneous result.
2. Is the agitator suitable for use in hazardous environments?
Yes, our agitator is built with robust construction and can be customized to meet specific safety requirements, making it suitable for hazardous environments.
3. How can I adjust the agitator speed to achieve the desired mixing intensity?
Our agitator comes with adjustable speed settings, allowing you to easily control the mixing intensity based on your specific requirements.
4. Can the agitator be installed on existing mixing tanks?
Yes, our agitator can be easily installed on existing mixing tanks, providing a cost-effective solution for upgrading your mixing equipment.
5. How do I clean and maintain the agitator for optimal performance?
We provide detailed cleaning and maintenance instructions. Regularly cleaning the agitator and following our guidelines will help ensure its longevity and optimal performance.
