Product Advantage：
1. It can complete the under-cover sealing of aerosol cans and liquid quantitative filling. Its control system uses the trendy PLC + touch screen machine. It is characterized by safe and reliable operation, good airtight sealing, measurement accuracy, and high precision of repeat filling.
2. This machine is specifically designed to handle the filling of a variety of aerosol products, including sprays, foams, and liquids. It features a user-friendly interface with a touchscreen display that allows operators to easily control and monitor the filling process. The machine is equipped with multiple filling nozzles, enabling the simultaneous filling of multiple cans.
3.The unique Bov system is developed to not only produce a superior spray dispensing system, but to reduce our ecological footprint through a sustainable packaging process. Compared to traditional aerosol spray technology (and other alternative packaging) BoV aerosols have benefits for manufacturers, consumers as well as the environment.
Technical Parameters:
Filling capacity (cans/min) | 45-60cans/min |
Liquid filling volume (ml) | 10-300ml/head |
Gas filling accuracy | ≤±1% |
Liquid filling accuracy | ≤±1% |
Applicable cans diameter (mm) | 35-70 ( can be customized) |
Applicable cans height (mm) | 70-300 ( can be customized) |
Applicable valve (mm) | 25.4 (1 inch) |
Propellant | N2, compressed air |
Max gas consumption (m3/min) | 6m3/min |
Power (KW) | AC 380V/50HZ |
Air source | 0.6-0.7Mpa |
Product Uses:
This set of equipment has been widely used in health, fire protection, cosmetics and other industries, such as water-based cleaning agents, disinfectants, household fire extinguishing agents, tear gas, shaving foam, cosmetic sprays, photocatalysts and other aerosol product bags. For economic reasons, there are more options for propellants, such as N2, CO2, Ar, LPG, and even compressed air.
We don`t know which kind of product you produce exactly. But our company could offer many kinds of machine(semi-auto/ full-auto/entire line ) for you to choose as your real need. So if you have any further request, please let us know.
House Care: air freshener, insecticide, furniture spray, pesticide, leather spray, toilet spray, glass spray.
Personal Care: perfume, deodorant, hair spray, shaving gel/foam, mouth spray, cosmetic spray, self-defence spray,
police spray.
Car Care: tyre repair spray, car windows spray, upholstery spray, engine cleaner spray.
Other Industries: spray painting, Pu foam, LPG cartridge, refrigerant gas, butane gas, fire extinguisher, anti-rust spray.
mould release spray.
FAQ:
1. How precise is the filling operation performed by a bag-on-valve machine?
Bag-on-valve filling machinery has a remarkable precision in fill quantities, ensuring reliable dosage consistency and minimizing variations during product distribution.
2. Does the bag-on-valve technology have an eco-friendly nature?
Yes, the bag-on-valve technology is considered eco-friendly as it can reduce the dependence on propellants and minimize product waste, thus offering a greener packaging option.
3. Can bag-on-valve filling machines handle both fluid and thick formulations?
Definitely. These machines are designed to handle a wide range of product consistencies, facilitating the filling process for both fluid and thick materials.
4. Do consumers feel safe using products packaged by the bag-on-valve method?
Yes, indeed. The bag-on-valve method ensures consumer safety by creating an isolating layer between the product and any propellant or compressed air, maintaining product purity and significantly lowering the risk of contamination.
5. How long does it take to fill a bag using a bag-on-valve filler?
The filling time varies depending on factors such as product thickness, the volume to be filled, and the speed of the machinery. However, bag-on-valve filling systems are set up for fast and efficient filling cycles.
