Model | Capacity(L) | Mixing | Homogenizing |
Power（kw） | Speed(r/min） | Power（kw） | Speed(r/min） |
WJ-LBD10 | 10 | 0.37 | 0-63 | 1.5 | 0-3000 |
WJ-LBD50 | 50 | 0.75 | 0-63 | 3 | 0-3000 |
WJ-LBD100 | 100 | 1.5 | 0-63 | 4 | 0-3000 |
WJ-LBD200 | 200 | 2.2 | 0-63 | 5.5 | 0-3000 |
WJ-LBD300 | 300 | 3 | 0-63 | 7.5 | 0-3000 |
WJ-LBD500 | 500 | 4 | 0-63 | 11 | 0-3000 |
Key Functions：Vacuuming, scrapers mixing, homogenizing, heating. Homogenizing installation: on top or at bottom Heating Method：Electric heating and steam heating（steam heating requires a steam generator） Other optional functions: Water pot and oil pot,circulation system, load cell system, water flow meter system
|
|Features
1）Hydraulic lift with one-touch height adjustment for easy loading, unloading, and maintenance;
2）304 stainless steel complies with GMP standards for safe contact with materials;
3）Compact body for easy installation, suitable for small to medium-sized settings;
4）Easy to clean, with a liftable pot lid and tiltable pot body;
5）Vacuum degassing meets sterile requirements.
|Application
used in cosmetic cream , BB cream , emulsion , daily chemical products , food saladketchup , medical ointment , etc.
|
Working Video
|
Comment & FAQ
1. What is the speed adjustment range of the equipment and how does it adapt to the process?
A: Variable frequency speed control from 0 to 3000 rpm, adjustable based on material viscosity and particle size. Low speeds are used for mixing viscous pastes, while high speeds achieve nano-level emulsification.
2. What are the advantages of the hydraulic lifting mechanism?
A: One-button height adjustment facilitates material loading/unloading, cleaning, and maintenance, reducing manual labor intensity. It is suitable for frequent material changes in laboratories and production line maintenance.
3. What are the materials and safety features of the components in contact with the material?
A: 304 stainless steel, corrosion-resistant and compliant with GMP standards, meeting the safety and hygiene requirements for food and pharmaceutical production.
4. What are the installation space requirements and suitable applications for the equipment?
A: Compact design with minimal space requirements, suitable for laboratories and small to medium-scale production lines, offering flexible installation and high space utilization.
5. Does it have vacuum degassing and sterile processing capabilities?
A: Vacuum degassing can be optionally configured, with vacuum extraction to remove bubbles. Combined with sterile process design, it meets the sterile production requirements of the pharmaceutical industry and others.
6.How convenient is the equipment for cleaning and maintenance?
A: The pot lid can be lifted and removed, and the emulsification pot tilts for discharge. The 304 stainless steel surface is smooth, enabling quick cleaning and minimizing residue.
used in cosmetic cream , BB cream , emulsion , daily chemical products , food saladketchup , medical ointment , etc.
