2024.6.5 update
Product Advantage:
1. High efficiency: The Vacuum Homogenizing Emulsifier can quickly and evenly mix materials to improve production efficiency.
2. Fine homogenization: It can produce emulsions and suspensions with fine particle sizes, uniform texture and stability.
3. Vacuum processing: The equipment uses vacuum processing technology to prevent oxidation and degradation of materials, and ensure product quality.
4. Easy to clean: The structure of the equipment is simple, easy to disassemble and clean, and can meet the requirements of hygiene and safety.
5. Wide application: It is widely used in food, pharmaceutical, chemical and other industries, and can produce various emulsions and suspensions.
Technical Parameters:
Model | Capacity(L) | Mixing | Homogenizing |
|
| Power（kw） | Speed(r/min） | Power（kw） | Speed(r/min） |
WJ-MM50 | 50 | 0.55 | 0-60 | 1.5 | 0-3000 |
WJ-MM100 | 100 | 0.75 | 0-60 | 1.5 | 0-3000 |
WJ-MM200 | 200 | 1.5 | 0-60 | 3 | 0-3000 |
WJ-MM300 | 300 | 2.2 | 0-60 | 4 | 0-3000 |
WJ-MM500 | 500 | 2.2 | 0-60 | 5.5 | 0-3000 |
WJ-MM1000 | 1000 | 4 | 0-60 | 11 | 0-3000 |
WJ-MM2000 | 2000 | 5.5 | 0-60 | 15 | 0-3000 |
WJ-MM3000 | 3000 | 7.5 | 0-50 | 18.5 | 0-3000 |
WJ-MM5000 | 5000 | 11 | 0-50 | 22 | 0-3000 |
Product Uses:
1. Food industry: Used in the production of dairy products, beverages, sauces, etc.
2. Pharmaceutical industry: Used in the production of emulsions, suspensions, and liposomes.
3. Cosmetics industry: Used in the production of lotions, creams, and shampoos.
4. Chemical industry: Used in the production of pesticides, coatings, and adhesives.
5. Biotechnology: Used in the production of cell suspensions and enzyme preparations.
Working principle:
Material is drawn into the working chamber by the strong centrifugal force generated by the high-speed rotation of the rotor. In the gap between the stator and rotor, the material undergoes shearing action, resulting in the breakup of dispersed particles or droplets. This process relies primarily on extremely high shear forces.
FAQ:
1. What determines the capacity of a Mixing tank with agitator?
It depends on the volume and nature of the substances to be mixed, as well as production requirements. For instance, a larger capacity is needed for high-volume production.
2. How does the agitator's design affect the mixing efficiency?
Different designs create different flow patterns. A well-matched design ensures thorough mixing. For example, a turbine agitator works better for some mixtures than a propeller one.
3. Are there specific cleaning procedures for this type of tank?
Yes. Usually, it involves flushing with appropriate solvents and thorough scrubbing. Special care is needed to remove residues that might affect subsequent mixes.
4. Can the agitator be replaced if it malfunctions?
Yes. But the replacement should match the tank's specifications. It might require professional installation to ensure proper functioning.
5. What kind of sealing is used to prevent leaks?
Commonly, mechanical seals or gaskets are used. Their selection depends on factors like the substances being mixed and the operating pressure.
